LOGICSTEEL XR
Quality control at a glance
LogicSteel XR is a quality control tool that uses Extended Reality (XR) to project 3D models directly onto steel assemblies, allowing real-time verification of accuracy during quality control. It eliminates the need for 2D drawings and manual measurements and streamlines the inspection process.
GET A QUOTE
HIGHLIGHTS
INSTANT QUALITY ASSURANCE
LogicSteel XR projects your 3D model directly onto the assembly through XR glasses, so you can instantly verify accuracy without drawings or measurements. Walk around and inspect from every angle for faster, more intuitive quality checks.
REPLACE 2D DRAWINGS WITH 3D OVERLAYS
With LogicSteel XR, quality control becomes fully paperless. You select the assemblies that require inspection, and the XR headset displays precise 3D overlays on the assembly, including all dimensions in metric or imperial. This paperless workflow prevents interpretation errors and ensures faultless production.
CATCH MISTAKES EARLY AND MAKE REWORK EASY
LogicSteel XR helps catch issues before an assembly leaves the shop, so corrections can be made early without disrupting production. Photos and videos captured through the headset provide clear evidence of the intended result, making any necessary rework straightforward and unambiguous.
OUR CUSTOMERS
EXPLORE FEATURES
GO PAPERLESS
In the XR Backoffice, all inspection results flow in instantly from the headset. You can review weld drawings, 3D models, and captured photos or videos, while managing quality controllers and monitoring the status of every assembly.
ALL-IN-ONE HEADSET
Carry out inspections and submit reports straight from the headset, with no extra devices or cables required.
FOR BIG ASSEMBLIES AND SMALL DETAILS
LogicSteel XR delivers precision accuracy down to 1.5mm (1/16"), even on assemblies as large as 18 meters (60 feet).
YEARLY LICENSES
1 - 2 LOCATIONS
2+ LOCATIONS
1 USER
- Unlimited access
- LogicSteel account
- Hardware sold separately
2 USERS
- 50% discount 2nd user
- Unlimited access
- LogicSteel account
- Hardware sold separately
3 USERS
- 50% discount 2nd user
- 75% discount 3rd user
- Unlimited access
- LogicSteel account
- Hardware sold separately
ENTERPRISE
- Pricing per license or location.
- Personalized pricing
- Hardware sold separately
HARDWARE
Included in the box is the Magic Leap 2 headset, Magic Leap 2 controller, Magic Leap 2 power source, carrying case, charging cable and manual.
Hardware for LogicSteel XR is sold separately.
QUESTIONS?
We are happy to help!
If you have any questions about LogicSteel XR or need help finding the right solution for your business, feel free to get in touch with us directly. For quick answers to common questions, check out the frequently asked questions below, where we’ve compiled a list of the questions we receive most often.
LogicSteel XR is Voortman's Extended Reality (XR) quality control tool for steel fabrication. LogicSteel XR solves the problem of slow, error-prone manual quality control by projecting a 3D model directly onto a physical steel assembly in real time, so inspectors can verify accuracy without 2D drawings or manual measurements. The result is a faster, more reliable inspection process with fewer errors and less rework.
LogicSteel XR is built for steel fabricators, quality controllers, and decision-makers who want to improve productivity, reduce errors, and streamline quality control for their steel assemblies.
LogicSteel XR achieves an accuracy of 1.5 mm (1/16"), making LogicSteel XR precise enough for the most demanding structural steel fabrication quality control workflows. LogicSteel XR supports assemblies up to 18 meters (60 ft) in length, covering the vast majority of steel components found in fabrication shops. LogicSteel XR also displays measurements directly on the beam, so inspectors always know exactly what distances should be without needing to reference separate drawings.
LogicSteel XR aligns automatically using a single QR code magnet. Attach the magnet to the steel beam, scan the QR code through the LogicSteel XR glasses, and the 3D overlay is instantly positioned onto the assembly. A quick fine-tune of the overlay ensures a perfect fit before inspection begins, and your team is up and running in no time.
LogicSteel XR integrates directly with Tekla Structures and SDS/2, so steel fabricators can use LogicSteel XR without changing their existing design workflow.
LogicSteel XR supports both metric and imperial units. The unit system is selectable directly in the XR app on the LogicSteel XR glasses, making it easy for teams in different regions to work in the system they are used to.
LogicSteel XR is available in seven languages:
- English
- Dutch
- German
- Spanish
- French
- Italian
- Polish
The language is set directly on the LogicSteel XR glasses, making LogicSteel XR easy to deploy across international teams and multi-site fabrication facilities.
LogicSteel XR achieves an accuracy of 1.5 mm (1/16") and supports steel assemblies up to 18 meters (60 ft) in length. The LogicSteel XR headset weighs 260 grams and runs on an AMD Quad-core Zen2 x86 processor, with a 120 Hz refresh rate, a resolution of 1440 x 1760 per eye, and a 70-degree diagonal field of view.
LogicSteel XR includes controller support, prescription lens support, and built-in dimming technology for varying light conditions on the shop floor. LogicSteel XR ships production-ready with one QR code magnet included and receives ongoing support and security updates.
LogicSteel XR receives continuous over-the-air updates, delivering new features and fixes directly to the glasses without long wait times or manual installation.
LogicSteel XR comes with full support through the Voortman customer service department, staffed by specialized LogicSteel XR experts. After purchasing LogicSteel XR, dedicated onboarding experts help your team get up and running quickly.
